Stainless Steel Idler Conveyor RS-1912

The gravity conveyor model is conveying medium loads

• Idler diameter is φ 48.6, idler pitch is min P50.
• Idler width(nominal) is 100W-1000W in standard increments of 50mm.
• Pressed bearing, low cost
• [ 90 standard frame

Ask For Price

The gravity conveyor model is conveying heavy loads

• Idler diameter is φ 57.2, wall thickness is t2.3, highly versatile for heavy loads, idler pitch is min P75.
• Idler width(nominal) is 100W-1000W in standard increments of 50mm.
• High quality with precision-machined bearing
• [ 90 standard frame

Ask For Price

The gravity conveyor model is conveying light loads, ideal for conveying small items

• Idler diameter is φ 38.1, idler pitch is min P50.
• Idler width(nominal) is 100W-600W in standard increments of 50mm.

Ask For Price

The gravity conveyor model is conveying light to medium loads

• For use with inner R700(mm), with an angle of 90°
• Idler width(nominal) is 200W-600W in standard increments of 50mm. Free sizes are also possible.

Ask For Price
