Belgotch Troughed Belt Model Type34-V1
The belt surface of Belgotch (Belt Conveyor) is troughed at the center, and this allows carrying small things and particulate works that are likely to be spilled without fail. The right and left belt support plates can easily be removed for cleaning etc.
- Aluminum frame
- Center drive
- Light weight model
